Field Rate

Description

Field frequency used (Hz).

Both field rate and resolution give the video standard.

Values

50.00 Hz (PAL) - default

59.94 Hz (NTSC)

59.94 Hz (J)

Resolution

Description

Vertical resolution used (number of white-to-black and black-
to-white transitions that can be seen from the top to the bottom
of the picture) (pixel + type).

Both field rate and resolution correspond to the video standard.

With an XSnano server, SD and HD video standards can be
available if the relevant license codes are activated.

Values

In SD:

525i

625i

In HD:

720p

1080i

Codec

Description

Algorithm used to compress and decompress the video signal.
The codecs available on the EVS server depend on the video
standard used, as well as on the active license codes.

See section "Codec Availability" on page 63 for detailed
information on codec availability.

Values

In SD:

DVCPro 50

In HD:

DVCPro HD

Bitrate

Description

Number of megabits processed per second (Mbps).

The bitrate depends on the codec.

Values

See section "Codec-Related Information" on page 63 for
detailed information on bitrates per codec,

61

3. Multicam Configuration

EVS Broadcast Equipment S.A. - November 2012

Issue 11.01.B
