Issue 5.9.B IPDirector Version 5.9 – User Manual – Part 3 – Browsing
EVS Broadcast Equipment – January 2011
22
3.2.1 C
LIP
E
LEMENT
T
YPES
A clip can contain up to six types of clip elements:
Clip Element Description
XT hi-res clip
hi-res clip or growing clip stored on an EVS
video server.
XT lo-res clip
lo-res clip or growing clip stored on an EVS
video server.
on-line hi-res nearline file hi-res file stored in nearline folders, IP drive is
on-line (accessible and managed).
on-line lo-res nearline file
lo-res files stored in nearline folders, IP drive is
on-line (accessible and managed).
off-line hi-res nearline file hi-res files stored in nearline folders, IP drive is
no more on-line.
off-line lo-res nearline file lo-res files stored in nearline folders, IP drive is
no more on-line.
Depending on user rights, the user can see different element types. The tables in
sections 2.4.2 ‘Tree Structure Depending on User Rights’ on page 13 and ‘List
View Button’ on page 4 give more details on the user rights.
Note
There can be several copies of the same element within a clip.
3.3 NEARLINE MANAGEMENT
XT clips can be sent to the nearline for backup purpose. They are saved on the
nearline as files. Physical storage such as IP drive (or XF drive) can be used as
nearline. A clip which only contains a nearline file can be restored to an EVS
video server, for example for playout purpose.
Once a nearline directory has been configured in the Remote Installer, the
IPDirector will continuously scan the directory path looking for new files or files
being deleted. The IP drive service will also automatically detect the appearance
of a new IP drive, or XFile disk, or the ejection of a drive.
