Page 340
190-00647-01 Rev. B
Garmin G1000 Pilot’s Guide for the Mooney M20M/M20R/M20TN
329
HAZARD AVOIDANCE
SY
STEM
O
VER
VIEW
FLIGHT
INSTRUMENTS
EIS
AUDIO P
ANEL
& CNS
FLIGHT
MANA
GEMENT
HAZARD
AV
OID
ANCE
AFCS
ADDITIONAL
FEA
TURES
APPENDICES
INDEX
8)
Press the FMS Knob or CLR Key to return to the Navigation Map Page.
Figure 6-74 Navigation Map Page Setup Menu
Figure 6-73 Navigation Map Page Menu
Figure 6-75 Navigation Map Page Setup Menu, Traffic Group
TAS ALERTS
NOTE:
Refer to the SKY497 documentation for information on alerts generated by the TAS equipment.
When the number of TAs on the Traffic Map Page increases from one scan to the next, the following occur:
• A TRAFFIC Annunciation appears at the top right of the airspeed on the PFD, flashing for 5 seconds and
remaining displayed until no TAs are detected in the area.
• The PFD Inset Map is automatically displayed with TA traffic
