8
Fig. 1
Figure 5: Console connection
4.3.3. System connection:
Please use Custom combo cable to connect your computers.
Please refer to the figures and instruction shown below for System
connection.
Note: Please contact your dealer to purchase the 4-in-1 combo cables if
you need. Order information : EK-C18C ( 1.8 meters ) ; EK-C30C
( 3 msters )
Figure 6: 4-in-1 Combo cable
