¾ A plus mark (+) showing in the left of channel name indicates that the port
has cascades.
7.1.3. Computer & KVM status
¾ KVM buzzer stauts
Buzzer sound on
Buzzer sound off
¾ Logined user name
The system has one administrator and 3 users for security management.
The name of current logined is displayed here.
¾ Channel LOCK indicator ( Status S TA )
L: Indicating this channel is locked.
BLANK: Indicating this channel is normal without locked.
¾ Computer power on indicator ( Status S T A ), OSD menu will update
the flag automatically if the computer status is changed
A: Indicating this computer is powered on and ready to select.
BLANK: Indicating this computer is not connected or powered on.
¾ Channel scan indicator ( Status ST A )
S: This channel is marked for auto-scan if the scan mode is Select type.
BLANK: Indicating this computer is not marked for auto-scan.
7.1.4. Current active channel number
Indicate current active channel number. The channel of the currently
selected computer is displayed in the right-upper corner.
If the active channel is in 2nd or 3rd cascade layer, the display string is like
XX-YY-ZZ. For example, 02-05-07 means the active channel is layer 1
channel 2 links to layer 2 channel 5, and layer 3 channel 7 is selected as
active channel.
7.1.5. Cascade parent channel number
Indicate the parent channel of this cascade layer. The number at the
left-upper corner below KVM layer number shows the number of port for
the upper layer, i.e. 8 means link from channel 8 of upper KVM.
It’s valid only for 2nd and 3rd cascade layer. It will show blank for 1st layer
since there is no parent channel.
7.1.6. Page down / up indicator
This is for EK-16RC only. The information of port 1 ~ 8 are display in the
