Edimax Technology EK-16RC User Manual

Page 25

7.4.3. Auto-scan mode

There are two auto-scan modes, please refer section 7.3.1 Setup in

OSD – Scan Mode to set up the auto-scan mode.
¾ Scan all computers which are power on.
¾ Scan all computers which are marked for auto-scan.

7.4.4. Auto-scan time interval

The auto-scan time interval of each port displayed can be adjustable by

pressing in OSD main menu. Please refer section 7.3.2 Setup in

OSD – Scan Time.

7.5. Console Lock in OSD:

If the security mode is enabled in OSD mode (by pressing in OSD mode,

please refer section 7.7 Security Setup in OSD). You can logout to lock

console by pressing In OSD mode. The Console Lock Banner will be

shown on the screen.

Figure 23: Console Lock Banner

The KVM will be locked until an authorized user login.

Figure 24: Unlock window

Note: You can also logout to lock console via hot key by using

→ → → outside the

OSD mode. Please refer section 6.7 Console Lock.

Note: If you forget the password, the only way to permanently
disable the security function is to key in a universal password to
unlock KVM. You need to key in this unlock password to release
your device and KVM, and then you can restart everything. Please
contact with your agency/distributor to get the universal password.
