5
z Package Contents
The product you purchased should contain the following equipment and
accessories:
1 x EK-08RC or EK-16RC Combo KVM Switch .
1 x User’s Manual.
1 x Power adaptor
1 x Rack Mount Kit
1 x 1.8 meters 4-in-1 combo cable
Cable Order information : EK-C18C ( 1.8 meters ) ; EK-C30C ( 3 msters )
2. Specifications
Specification
Number Of Computers Controlled 8 or 16
Selection Method
Push Button and Hot-Key (PS/2 / USB Keyboard)
Or On-Screen-Display (OSD)
LEDs
Red for PC Selection
Green for PC On-Line ready
Video 8 / 16 x HDB-15 female
PC Connectors
(KB/MS) ( PS/2 & USB signal combined )
Keyboard 1 x 6 pin mini-DIN female
Mouse 1 x 6 pin mini-DIN female
Video 1 x HDB-15 female
Keyboard 1 x USB – A type female
Console Ports
Mouse 1 x USB – A type female
Auto-Scan Interval Adjustable time setting by OSD menu driven
DDC, DDC2 monitor Yes (Max. Resolution up to 2048 x1536)
Hot Swappable Yes
Operating systems supported
Windows 98SE/ME/2000/XP/2003/Vista Server,
Linux, Mac OS9/OSX and Sun Microsystems.
Power By external power adaptor
Dimensions (L X W X H) 44 x 15.7 x 4.5 cm (17.3 x 6.1 x 1.5 inch )
Unit Weight 1750g / 1900 g
Housing material Metal
Operating Temperature 32~ 122°F (0~ 50°C )
Humidity 0%~80%RH
Firmware upgrade connector Mini USB female
