Printer requirements and specifications
Installation Planning Guide 6-23
The following table lists the turning requirements for the printer if
it is upended for easier moving or stair-climbing. This table
reflects requirements for the printer separated from the PHM.
Turning radius for
unseparated
printer
components
The following table lists the turning requirements for the printer
when attached to the paper handling module (not separated).
Table 6-7.Turning radius for printer (separated and upended
on dolly)
Passage or doorway A width Minimum passage B width
30 inches / 76.2 cm 49 inches / 124.5 cm
31 inches / 78.7 cm 43 inches / 109.2 cm
32 inches / 81.3 cm 41 inches / 104.1 cm
34 inches / 86.4 cm 37.5 inches / 95.3 cm
36 inches / 91.4 cm 35 inches / 88.9 cm
38 inches / 96.5 cm 33.5 inches / 85.1 cm
40 inches / 101.6 cm 32 inches / 81.3 cm
42 inches / 106.7 cm 31 inches / 78.7 cm
Table 6-8. Turning radius for printer (not separated)
Passage or doorway A width Minimum passage B width
29 inches / 73.7 cm 83 inches / 210.8 cm
30 inches / 76.2 cm 76 inches / 193 cm
31 inches / 78.7 cm 73 inches / 185.4 cm
32 inches / 81.3 cm 70.5 inches / 179.1 cm
34 inches / 86.4 cm 66.5 inches / 169 cm
36 inches / 91.4 cm 63.5 inches / 161.3 cm
38 inches / 96.5 cm 61.5 inches / 156.2 cm
40 inches / 101.6 cm 58 inches / 147.3 cm
42 inches / 106.7 cm 55 inches / 139.7 cm
