Printer requirements and specifications
6-22 Installation Planning Guide
Using the turning
radius tables
To use the tables:
1. Measure the minimum width of the passage or doorway you
need to use. This is Passage A.
2. Find that number (or the next higher number) in the turning
radius table and read across to the corresponding minimum
value for Passage B, depending on the type of turn the
equipment must negotiate.
Turning radius for
printer with
separated
components
The printing system is delivered with the printer, inverter feeder/
stacker, and each feeder/stacker as separate modules. If
necessary, the printer can be separated into two pieces for ease
in moving. The larger of the two parts contains the xerographic
system; the smaller of the parts (the paper handling module, or
PHM) contains paper trays 1 and 2. Do not confuse these two
parts of the printer with the inverter and feeder/stacker modules,
which have their own turning requirements.
The following table lists the turning requirements for the printer
without the PHM (separated).
Table 6-6. Turning radius for printer (separated)
Passage or doorway A width Minimum passage B width
29 inches / 73.7 cm 74.5 inches / 189.2 cm
30 inches / 76.2 cm 64.5 inches / 163.8 cm
31 inches / 78.7 cm 62 inches / 157.5 cm
32 inches / 81.3 cm 59.5 inches / 151.1 cm
34 inches / 86.4 cm 56 inches / 142.2 cm
36 inches / 91.4 cm 53 inches / 134.6 cm
38 inches / 96.5 cm 50 inches / 127 cm
40 inches / 101.6 cm 48 inches / 121.9 cm
42 inches / 106.7 cm 45.5 inches / 115.6 cm
