Prestige 314 PLUS Broadband Sharing Gateway with 4-Port Switch
NAT 4-9
SUA Address Mapping Set
Enter 255 to display the next screen (see also section 4.2.1). The fields in this menu cannot be changed.
Figure 4-7 Menu 15.1.255 — SUA Address Mapping Rules
The following table explains the fields in this screen.
The fields in menu 15.1.255 are read-only.
Table 4-4 SUA Address Mapping Rules
FIELD DESCRIPTION EXAMPLE
Set Name This is the name of the set you selected in menu
15.1 or enter the name of a new set you want to
create. SUA
Idx This is the index or rule number. 1
Local Start IP
Local End IP
Local Start IP is the starting local IP address (ILA)
(see Figure 4-1). Local End IP is the ending local
IP address (ILA). If the rule is for all local IPs, then
the Start IP is 0.0.0.0 and the End IP is
255.255.255.255. 0.0.0.0
255.255.255.255
Menu 15.1.255 - Address Mapping Rules
Set Name= SUA
Idx Local Start IP Local End IP Global Start IP Global End IP Type
--- --------------- --------------- --------------- --------------- ------
1. 0.0.0.0 255.255.255.255 0.0.0.0 M-1
2. 0.0.0.0 Server
3.
4.
5.
6.
7.
8.
9.
10.
Press ENTER to Confirm or ESC to Cancel:
