Prestige 314 PLUS Broadband Sharing Gateway with 4-Port Switch
Getting to Know Your Prestige 1-5
Table 1-1 Internet Access Configuration Checklist
SMT # FIELD ACTION
1 System Name This field is for identification purposes but because some ISPs check this name
you should enter your computer’s “Computer Name”.
• In Windows 95/98 click Start, Settings, Control Panel, Network. Click the
Identification tab, note the entry for the Computer Name field and enter it as the
System Name.
• In Windows 2000, click Start, Settings, Control Panel, Network
Identification. Click the Identification tab, note the entry for the Computer
Name field and enter it as the System Name.
• In Windows XP, click Start, Control Panel, System. Click the Computer
Name tab. Note the entry for the Computer Description field and enter it as the
System Name.
2 MAC Address:
Assigned By
The default is Factory Default, which is the factory assigned default MAC
Address. We recommend you choose IP Address attached on LAN and enter
the IP address of the workstation on the LAN whose MAC you are cloning.
4 Encapsulation Choose PPPoE if you have a dial-up connection to the Internet (or PPTP if you
reside in France or Austria); otherwise choose Ethernet. Choose from RR-
Manager, RR-Telstra or RR- Toshiba if your ISP is Time Warner's RoadRunner;
otherwise choose Standard.
PPTP You need to know your login name, password and connection ID/Name. The latter
may not be obligatory for some ISPs, but if it is you must follow the “c:id” and
“n:name” format.
PPPoE You need to know your login name, password and service name. The latter may
not be obligatory for some ISPs.
IP Address
Assignment
If your ISP did not assign you a fixed IP address, select Dynamic, otherwise
select Static and enter the IP address & subnet mask in the IP address and IP
Subnet Mask fields.
Once these key fields have been configured, you should be able to enjoy super-fast Internet access with your
Prestige!
