Prestige 314 PLUS Broadband Sharing Gateway with 4-Port Switch
Hardware Installation & Initial Setup 2-15
FIELD DESCRIPTION EXAMPLE
IP Address This field is applicable only if you choose the IP Address attached
on LAN method in the Assigned By field above. Enter the IP
address of the workstation on the LAN whose MAC you are cloning.
192.168.1.33
When you have completed this menu, press [ENTER] at the prompt “Press ENTER to Confirm…” to save
your configuration, or press [ESC] at any time to cancel.
Your Prestige WAN Port is always set at half-duplex mode as most cable modems only support half-duplex
mode. If your cable modem supports full-duplex mode, then you will be able to manually set it at half-duplex
mode. If the Prestige is set at half-duplex mode and the cable modem is set at full-duplex mode, then the
WAN port will not function properly.
Your Prestige supports full duplex mode on the LAN side.
2.10 LAN Setup
This section describes how to configure the LAN using Menu 3 — LAN Setup. From the main menu, enter
3 to display menu 3 (shown next).
Figure 2-10 Menu 3 — LAN Setup
2.10.1 LAN Port Filter Setup
This menu allows you to specify the filter sets that you wish to apply to the LAN traffic. You seldom need to
filter the LAN traffic, however, the filter sets may be useful to block certain packets, reduce traffic and
prevent security breaches.
Menu 3 - LAN Setup
1. LAN Port Filter Setup
2. TCP/IP and DHCP Setup
Enter Menu Selection Number:
