Filter Configuration 7-19
Figure 7-16 Filtering LAN Traffic
7.5.2 Remote Node Filters
Go to menu 11.5 (shown next – note that call filter sets are only present for PPPoE encapsulation) and enter
the number(s) of the filter set(s) as appropriate. You can cascade up to four filter sets by entering their
numbers separated by commas. The factory default filter set, NetBIOS_WAN, can be applied in menu 11.5
to block local NetBIOS traffic from triggering calls to the ISP (when you are using PPPoE or PPTP
encapsulation only). Enter 1 in protocol filters under Output Filter Sets when using Ethernet encapsulation,
and in the protocol filters field under Call Filter Sets when using PPPoE or PPTP encapsulation. Apply
them as shown in the following figure.
Figure 7-17 Filtering Remote Node Traffic
Menu 3.1 – LAN Port Filter Setup
Input Filter Sets:
protocol filters= 2
device filters=
Output Filter Sets:
Protocol filters=
device filters=
Press ENTER to Confirm or ESC to Cancel:
Apply
factory
default
filter
here.
Menu 11.5 - Remote Node Filter
Input Filter Sets:
protocol filters= 3
device filters=
Output Filter Sets:
protocol filters= 1
device filters=
Call Filter Sets:
protocol filters= 1
device filters=
Enter here to CONFIRM or ESC to CANCEL:
Apply
factory
default
Filters
here.
