Prestige 314 PLUS Broadband Sharing Gateway with 4-Port Switch
11-2 System Information & Diagnosis
11.1.1 To get to the System Status:
• Enter 24 to display Menu 24 - System Maintenance.
• In this menu, enter number 1 to open System Maintenance - Status.
• There are three commands in Menu 24.1 - System Maintenance - Status. Entering 1 drops the WAN
(PPTP/PPPoE) connection, 9 resets the counters and [ESC] takes you back to the previous screen.
The table below describes the fields present in Menu 24.1 - System Maintenance - Status. It should be
noted that these fields are READ-ONLY and are meant to be used for diagnostic purposes.
Figure 11-2 Menu 24.1 — System Maintenance — Status
The following table describes the fields present in Menu 24.1 - System Maintenance - Status.
Table 11-1 System Maintenance — Status Menu Fields
FIELD DESCRIPTION
Port The WAN or LAN port.
Status Shows the port speed and duplex setting if you’re using Ethernet
Encapsulation and Down (line is down), idle (line (ppp) idle), dial
(starting to trigger a call) and drop (dropping a call) if you’re using
PPPoE Encapsulation.
Menu 24.1 -- System Maintenance – Status 1:39:06
Thu. Jan. 1. 1970
Port
WAN
LAN
Status
100M/Full
100M/Full
TxPkts
1
0
RxPkts
0
0
Cols
0
0
Tx B/s
0
0
Rx B/s
0
0
Up Time
0:00:00
0:00:00
Port:
WAN
LAN
Ethernet Address
00:a0:c5:21:8c:a3
00:a0:c5:21:8c:a2
IP Address
0.0.0.0
192.168.1.1
IP Mask
0.0.0.0
255.255.255.0
DHCP
Client
Server
System up Time: 1:08:22
Name:
Routing: IP
ZyNOS F/W Version: V3.60(CX.0)b2 | 07/02/2002
Press Command:
COMMANDS: 1-Drop WAN 9-Reset Counters ESC-Exit
