251933-YTG-J-1009
Johnson Controls Unitary Products 97
XP036-060
Size
(Tons)
Weight (lbs.) Center of Gravity 4 Point Load Location (lbs.) 6 Point Load Location (lbs.)
Shipping Operating X Y A B C D A B C D E F
036
(3.0)
580 575 39 20 135 121 151 168 91 85 80 99 106 114
048
(4.0)
590 585 39 20 137 124 154 171 93 87 81 101 108 116
060
(5.0)
595 590 39 20 138 125 155 172 94 87 82 102 109 117
ZF/ZR/XP036-060 Unit Accessory Weights
Unit Accessory
Weight (lbs.)
Shipping Operating
Economizer 55 50
Power Exhaust 55 50
Electric Heat 1
1. Weight given is for the maximum heater size available
(30KW).
28 28
Gas Heat 2
2. Weight given is for the maximum number of tube heat
exchangers available (5 tube).
70 70
