York R-410A - Manual (Page 33)

251933-YTG-J-1009
Johnson Controls Unitary Products 33
ZR060 (5.0 Ton) Cooling
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity 1
(MBh)
Total
Input
(kW) 2
Sensible Capacity (MBh) Total
Capacity 1
(MBh)
Total
Input
(kW) 2
Sensible Capacity (MBh)
CFM
WB
(°F) Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
1250
77 69.5 3.7 26.9 22.4 17.9 - - - 66.6 4.2 26.7 22.1 17.5 - - -
72 63.9 3.6 35.1 30.6 26.1 21.7 - - 61.1 4.2 34.8 30.2 25.6 21.0 - -
67 58.4 3.6 43.3 38.8 34.3 29.9 25.4 - 55.6 4.2 42.8 38.2 33.6 29.0 24.4 -
62 53.1 3.6 53.1 45.4 41.0 36.6 32.1 27.6 50.5 4.1 50.5 46.1 40.8 36.2 31.6 26.9
1500
77 75.4 3.7 31.5 26.1 20.6 - - - 71.7 4.2 30.7 25.2 19.8 - - -
72 69.4 3.7 40.9 35.5 30.0 24.5 - - 65.8 4.2 39.8 34.3 28.8 23.4 - -
67 63.4 3.7 50.3 44.9 39.4 33.9 28.4 - 59.9 4.2 48.9 43.4 37.9 32.4 27.0 -
62 57.7 3.6 57.7 52.5 47.0 41.6 36.1 30.6 54.4 4.1 54.4 51.5 46.0 40.5 35.1 29.6
57 55.2 3.6 55.2 55.2 50.2 44.7 39.2 33.7 52.6 4.2 52.6 52.6 48.2 42.7 37.2 31.7
1750
77 81.4 3.8 36.2 29.7 23.2 - - - 76.9 4.3 34.7 28.4 22.0 - - -
72 74.9 3.7 46.8 40.3 33.8 27.3 - - 70.6 4.2 44.8 38.5 32.1 25.8 - -
67 68.4 3.7 57.4 50.9 44.4 37.9 31.4 - 64.2 4.2 54.9 48.6 42.2 35.9 29.5 -
62 62.2 3.6 62.2 59.6 53.1 46.6 40.1 33.6 58.3 4.2 58.3 56.9 51.2 44.9 38.6 32.2
57 59.6 3.6 59.6 59.6 56.6 50.0 43.5 37.0 56.4 4.2 56.4 56.4 53.7 47.3 41.0 34.6
2000
77 87.3 3.8 40.9 33.3 25.8 - - - 82.1 4.3 38.7 31.5 24.3 - - -
72 80.4 3.8 52.7 45.2 37.6 30.1 - - 75.3 4.3 49.8 42.6 35.4 28.2 - -
67 73.4 3.7 64.5 57.0 49.4 41.9 34.4 - 68.6 4.2 61.0 53.8 46.5 39.3 32.1 -
62 66.8 3.7 66.8 66.8 59.1 51.6 44.0 36.5 62.3 4.2 62.3 62.3 56.5 49.3 42.0 34.8
57 63.9 3.7 63.9 63.9 63.0 55.4 47.9 40.4 60.2 4.2 60.2 60.2 59.1 51.9 44.7 37.5
2250
72 82.4 3.8 55.2 47.2 39.2 31.3 - - 77.1 4.3 52.9 45.1 37.2 29.4 - -
67 75.2 3.7 67.5 59.5 51.6 43.6 35.6 - 70.1 4.2 64.6 56.8 49.0 41.1 33.3 -
62 68.4 3.7 68.4 68.4 61.7 53.8 45.8 37.8 63.7 4.2 63.7 63.7 59.4 51.6 43.8 35.9
57 65.5 3.7 65.5 65.5 65.0 57.1 49.1 41.1 61.5 4.2 61.5 61.5 61.0 53.2 45.4 37.6
2500
72 84.4 3.7 57.7 49.3 40.9 32.4 - - 78.8 4.3 55.9 47.5 39.1 30.6 - -
67 77.0 3.7 70.5 62.1 53.7 45.2 36.8 - 71.7 4.2 68.2 59.8 51.4 42.9 34.5 -
62 70.1 3.7 70.1 70.1 64.4 56.0 47.5 39.1 65.2 4.2 65.2 65.2 62.3 53.9 45.5 37.0
57 67.1 3.7 67.1 67.1 67.1 58.7 50.3 41.8 62.9 4.2 62.9 62.9 62.9 54.5 46.1 37.7
95°F 105°F
1250
77 63.7 4.8 26.6 21.8 17.1 - - - 59.2 5.4 24.5 19.8 15.2 - - -
72 58.2 4.7 34.5 29.7 25.0 20.2 - - 54.0 5.4 32.4 27.8 23.1 18.4 - -
67 52.8 4.7 42.4 37.6 32.9 28.1 23.4 - 48.9 5.3 40.3 35.7 31.0 26.3 21.6 -
62 47.9 4.7 47.9 46.8 40.5 35.8 31.0 26.3 44.6 5.3 44.6 44.1 37.9 33.2 28.5 23.9
1500
77 68.1 4.8 29.9 24.4 19.0 - - - 63.1 5.4 27.6 22.2 16.9 - - -
72 62.3 4.8 38.7 33.2 27.7 22.2 - - 57.6 5.4 36.4 31.0 25.6 20.3 - -
67 56.5 4.7 47.4 41.9 36.5 31.0 25.5 - 52.1 5.3 45.2 39.8 34.4 29.1 23.7 -
62 51.2 4.7 51.2 50.4 45.0 39.5 34.0 28.6 47.6 5.3 47.6 47.2 42.2 36.8 31.4 26.0
57 49.9 4.7 49.9 49.9 46.2 40.7 35.3 29.8 46.7 5.3 46.7 46.7 42.8 37.5 32.1 26.7
1750
77 72.5 4.8 33.2 27.0 20.8 - - - 67.1 5.4 30.7 24.6 18.5 - - -
72 66.3 4.8 42.8 36.6 30.4 24.3 - - 61.2 5.4 40.4 34.3 28.2 22.1 - -
67 60.1 4.7 52.4 46.3 40.1 33.9 27.7 - 55.3 5.3 50.1 44.0 37.9 31.8 25.7 -
62 54.5 4.7 54.5 54.1 49.4 43.2 37.0 30.9 50.6 5.3 50.6 50.4 46.4 40.3 34.2 28.1
57 53.2 4.7 53.2 53.2 50.7 44.6 38.4 32.2 49.6 5.3 49.6 49.6 47.2 41.1 35.0 28.9
2000
77 76.9 4.8 36.5 29.6 22.7 - - - 71.0 5.4 33.8 27.0 20.2 - - -
72 70.3 4.8 47.0 40.1 33.2 26.3 - - 64.8 5.4 44.4 37.6 30.8 24.0 - -
67 63.8 4.7 57.5 50.6 43.7 36.8 29.9 - 58.6 5.3 55.0 48.2 41.4 34.6 27.8 -
62 57.8 4.7 57.8 57.8 53.9 46.9 40.0 33.1 53.5 5.3 53.5 53.5 50.6 43.8 37.1 30.3
57 56.4 4.7 56.4 56.4 55.3 48.4 41.5 34.6 52.5 5.3 52.5 52.5 51.5 44.7 37.9 31.1
2250
72 71.8 4.8 50.5 42.9 35.2 27.6 - - 66.0 5.4 47.7 40.2 32.7 25.2 - -
67 65.1 4.7 61.7 54.0 46.4 38.7 31.0 - 59.7 5.3 57.7 51.4 43.9 36.4 28.9 -
62 59.0 4.7 59.0 59.0 57.0 49.4 41.7 34.1 54.5 5.3 54.5 54.5 53.1 45.5 38.0 30.5
57 57.6 4.7 57.6 57.6 57.0 49.4 41.7 34.1 53.5 5.3 53.5 53.5 53.0 45.5 37.9 30.4
2500
72 73.3 4.8 54.1 45.7 37.3 28.8 - - 67.1 5.4 51.0 42.8 34.6 26.3 - -
67 66.5 4.8 65.9 57.5 49.0 40.6 32.2 - 60.7 5.3 60.4 54.6 46.4 38.2 30.0 -
62 60.2 4.7 60.2 60.2 60.2 51.8 43.4 35.0 55.5 5.3 55.5 55.5 55.5 47.3 39.0 30.8
57 58.8 4.7 58.8 58.8 58.8 50.3 41.9 33.5 54.5 5.3 54.5 54.5 54.5 46.2 38.0 29.8
