York R-410A - Manual (Page 39)

251933-YTG-J-1009
Johnson Controls Unitary Products 39
XP048 (4.0 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity 1
(MBh)
Total
Input
(kW) 2
Sensible Capacity (MBh) Total
Capacity 1
(MBh)
Total
Input
(kW) 2
Sensible Capacity (MBh)
CFM
WB
(°F) Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
1000
77 60.0 2.8 26.9 22.4 18.0 - - - 54.8 3.2 22.8 18.7 14.6 - - -
72 55.2 2.8 33.0 28.6 24.2 19.8 - - 50.4 3.2 29.4 25.4 21.3 17.2 - -
67 50.3 2.8 39.2 34.9 30.5 26.1 21.7 - 46.0 3.2 36.1 32.0 27.9 23.8 19.8 -
62 45.1 2.8 45.1 43.9 37.8 33.4 29.0 24.6 40.8 3.2 40.8 39.6 33.4 29.3 25.2 21.1
1200
77 61.8 2.8 29.3 24.4 19.5 - - - 57.0 3.2 25.6 20.9 16.2 - - -
72 56.8 2.8 35.9 31.0 26.1 21.3 - - 52.5 3.2 33.0 28.3 23.6 18.8 - -
67 51.7 2.8 42.6 37.7 32.8 27.9 23.0 - 47.9 3.2 40.4 35.7 30.9 26.2 21.5 -
62 46.5 2.8 46.5 45.6 40.7 35.9 31.0 26.1 42.5 3.2 42.5 41.7 37.0 32.3 27.5 22.8
57 46.8 2.8 46.8 46.8 43.2 38.3 33.4 28.5 42.3 3.2 42.3 42.3 38.2 33.5 28.8 24.0
1400
77 63.6 2.8 31.6 26.4 21.0 - - - 59.3 3.2 28.5 23.1 17.8 - - -
72 58.4 2.8 38.8 33.4 28.0 22.7 - - 54.6 3.2 36.6 31.2 25.9 20.5 - -
67 53.2 2.8 46.0 40.5 35.1 29.7 24.4 - 49.8 3.2 44.7 39.3 34.0 28.6 23.2 -
62 47.8 2.8 47.8 47.4 43.7 38.3 32.9 27.5 44.2 3.2 44.2 43.8 40.6 35.2 29.9 24.5
57 48.2 2.8 48.2 48.2 46.3 41.0 35.6 30.2 44.0 3.2 44.0 44.0 41.9 36.6 31.2 25.8
1600
77 65.4 2.8 34.0 28.3 22.5 - - - 61.6 3.2 31.4 25.4 19.3 - - -
72 60.0 2.8 41.7 35.8 29.9 24.1 - - 56.6 3.2 40.2 34.2 28.2 22.1 - -
67 54.7 2.8 49.3 43.3 37.4 31.5 25.7 - 51.7 3.2 49.0 43.0 37.0 31.0 24.9 -
62 49.2 2.8 49.2 49.2 46.6 40.8 34.9 29.0 45.9 3.2 45.9 45.9 44.2 38.2 32.2 26.1
57 49.5 2.8 49.5 49.5 49.5 43.7 37.8 31.9 45.7 3.2 45.7 45.7 45.7 39.6 33.6 27.6
1800
72 61.4 2.8 45.7 39.0 32.3 25.6 - - 57.1 3.2 43.0 36.4 29.7 23.1 - -
67 56.0 2.8 53.3 47.2 40.5 33.8 27.1 - 52.1 3.2 50.8 45.7 39.1 32.4 25.8 -
62 50.3 2.8 50.3 50.3 49.0 42.3 35.6 28.9 46.3 3.2 46.3 46.3 45.4 38.8 32.2 25.5
57 50.6 2.8 50.6 50.6 50.6 43.9 37.2 30.5 46.0 3.2 46.0 46.0 46.0 39.4 32.7 26.1
2000
72 62.8 2.8 49.8 42.3 34.7 27.2 - - 57.5 3.2 45.8 38.5 31.3 24.1 - -
67 57.2 2.8 57.2 51.1 43.6 36.1 28.5 - 52.5 3.2 52.5 48.4 41.1 33.9 26.7 -
62 51.4 2.8 51.4 51.4 51.4 43.9 36.4 28.8 46.6 3.2 46.6 46.6 46.6 39.4 32.1 24.9
57 51.7 2.8 51.7 51.7 51.7 44.2 36.7 29.2 46.3 3.2 46.3 46.3 46.3 39.1 31.9 24.7
95°F 105°F
1000
77 49.5 3.6 18.7 15.0 11.2 - - - 45.8 3.9 17.2 14.4 10.7 - - -
72 45.6 3.6 25.8 22.1 18.3 14.5 - - 42.3 4.0 24.8 21.1 17.4 13.7 - -
67 41.7 3.6 33.0 29.1 25.4 21.6 17.8 - 38.7 4.0 32.4 27.9 24.2 20.5 16.8 -
62 36.5 3.6 36.5 35.4 29.0 25.2 21.5 17.7 34.2 4.0 34.2 33.7 27.7 24.0 20.3 16.6
1200
77 52.3 3.6 22.0 17.5 12.9 - - - 48.0 4.0 21.0 16.6 12.1 - - -
72 48.2 3.6 30.1 25.6 21.0 16.4 - - 44.3 4.0 28.7 24.2 19.7 15.3 - -
67 44.1 3.6 38.2 33.7 29.1 24.5 19.9 - 40.6 4.0 36.4 31.9 27.4 22.9 18.5 -
62 38.6 3.6 38.6 37.8 33.3 28.7 24.1 19.5 35.9 4.0 35.9 35.5 31.4 26.9 22.4 18.0
57 37.8 3.5 37.8 37.8 33.3 28.7 24.1 19.5 35.6 4.0 35.6 35.6 31.4 27.0 22.5 18.0
1400
77 55.0 3.6 25.4 19.9 14.5 - - - 50.3 4.0 24.9 18.8 13.5 - - -
72 50.7 3.6 34.4 29.1 23.7 18.3 - - 46.4 4.0 32.6 27.3 22.1 16.8 - -
67 46.4 3.6 43.5 38.2 32.8 27.4 22.1 - 42.5 4.0 40.4 35.9 30.6 25.4 20.1 -
62 40.6 3.6 40.6 40.3 37.5 32.2 26.8 21.4 37.6 4.0 37.6 37.4 35.1 29.8 24.6 19.3
57 39.8 3.5 39.8 39.8 37.5 32.2 26.8 21.4 37.2 4.0 37.2 37.2 35.1 29.9 24.6 19.3
1600
77 57.8 3.6 28.7 22.4 16.2 - - - 52.5 4.0 28.7 21.0 14.9 - - -
72 53.3 3.6 38.7 32.6 26.4 20.2 - - 48.4 4.0 36.5 30.5 24.4 18.3 - -
67 48.7 3.6 48.7 42.7 36.6 30.4 24.2 - 44.4 4.0 44.4 39.9 33.9 27.8 21.8 -
62 42.7 3.6 42.7 42.7 41.8 35.6 29.4 23.3 39.2 4.0 39.2 39.2 38.8 32.7 26.7 20.6
57 41.8 3.5 41.8 41.8 41.8 35.6 29.4 23.3 38.8 4.0 38.8 38.8 38.8 32.8 26.7 20.7
1800
72 52.7 3.6 40.3 33.7 27.1 20.6 - - 48.0 4.0 38.1 31.5 24.9 18.3 - -
67 48.2 3.6 48.2 44.2 37.6 31.1 24.5 - 43.9 4.0 43.9 41.2 34.6 28.0 21.4 -
62 42.2 3.6 42.2 42.2 41.8 35.2 28.7 22.1 38.8 4.0 38.8 38.8 38.6 32.0 25.4 18.8
57 41.4 3.6 41.4 41.4 41.4 34.8 28.3 21.7 38.5 4.0 38.5 38.5 38.5 31.9 25.3 18.7
2000
72 52.2 3.6 41.8 34.8 27.9 21.0 - - 47.5 4.0 39.7 32.6 25.4 18.3 - -
67 47.7 3.6 47.7 45.6 38.7 31.8 24.9 - 43.5 4.0 43.5 42.4 35.3 28.1 21.0 -
62 41.8 3.6 41.8 41.8 41.8 34.9 27.9 21.0 38.5 4.0 38.5 38.5 38.5 31.3 24.2 17.0
57 40.9 3.6 40.9 40.9 40.9 34.0 27.1 20.2 38.1 4.0 38.1 38.1 38.1 30.9 23.8 16.7
