York R-410A - Manual (Page 21)

251933-YTG-J-1009
Johnson Controls Unitary Products 21
ZF048 (4.0 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity 1
(MBh)
Total
Input
(kW) 2
Sensible Capacity (MBh) Total
Capacity 1
(MBh)
Total
Input
(kW) 2
Sensible Capacity (MBh)
CFM
WB
(°F) Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
1000
77 62.7 2.8 24.5 20.6 16.7 - - - 58.6 3.2 23.0 19.2 15.3 - - -
72 57.1 2.8 31.1 27.2 23.3 19.4 - - 53.5 3.2 29.6 25.8 22.0 18.2 - -
67 51.5 2.8 37.7 33.8 29.9 26.0 22.1 - 48.5 3.2 36.3 32.5 28.7 24.9 21.1 -
62 48.1 2.8 48.1 40.3 36.4 32.5 28.7 24.8 44.7 3.2 44.7 39.0 34.6 30.8 27.0 23.2
1200
77 63.8 2.9 26.8 22.4 18.1 - - - 60.0 3.2 25.3 21.0 16.7 - - -
72 58.1 2.8 33.9 29.6 25.2 20.9 - - 54.8 3.2 32.6 28.3 24.0 19.7 - -
67 52.4 2.8 41.0 36.7 32.4 28.0 23.7 - 49.6 3.2 39.8 35.5 31.2 26.9 22.6 -
62 49.0 2.8 49.0 43.8 39.4 35.1 30.7 26.4 45.7 3.2 45.7 42.0 37.7 33.4 29.1 24.8
57 47.2 2.8 47.2 46.8 42.4 38.1 33.7 29.4 45.2 3.2 45.2 44.9 40.6 36.3 32.0 27.7
1400
77 64.9 2.9 29.0 24.2 19.5 - - - 61.4 3.2 27.7 22.9 18.1 - - -
72 59.1 2.8 36.7 31.9 27.1 22.4 - - 56.1 3.2 35.5 30.7 25.9 21.1 - -
67 53.3 2.8 44.4 39.6 34.8 30.0 25.3 - 50.8 3.2 43.4 38.6 33.8 29.0 24.2 -
62 49.8 2.8 49.8 47.2 42.4 37.6 32.8 28.1 46.8 3.2 46.8 44.9 40.7 35.9 31.1 26.4
57 48.0 2.8 48.0 47.8 45.6 40.8 36.1 31.3 46.2 3.2 46.2 46.1 44.0 39.2 34.4 29.6
1600
77 66.0 2.9 31.3 26.1 20.8 - - - 62.8 3.3 30.0 24.7 19.4 - - -
72 60.1 2.8 39.5 34.3 29.0 23.8 - - 57.4 3.2 38.5 33.2 27.9 22.6 - -
67 54.2 2.8 47.7 42.5 37.3 32.0 26.8 - 51.9 3.2 46.9 41.6 36.3 31.0 25.7 -
62 50.7 2.8 50.7 50.7 45.4 40.2 34.9 29.7 47.9 3.2 47.9 47.9 43.8 38.5 33.2 27.9
57 48.8 2.8 48.8 48.8 48.8 43.6 38.4 33.2 47.3 3.2 47.3 47.3 47.3 42.0 36.7 31.4
1800
72 61.9 2.9 42.4 36.7 31.0 25.3 - - 58.7 3.2 41.1 35.4 29.6 23.9 - -
67 55.9 2.8 51.6 45.5 39.8 34.1 28.3 - 53.1 3.2 50.1 44.3 38.6 32.8 27.1 -
62 52.2 2.8 52.2 52.2 48.8 43.1 37.4 31.7 49.0 3.2 49.0 49.0 46.6 40.8 35.1 29.3
57 50.3 2.8 50.3 50.3 50.3 44.6 38.9 33.2 48.3 3.2 48.3 48.3 48.3 42.6 36.8 31.1
2000
72 63.7 2.9 45.4 39.2 33.0 26.8 - - 59.9 3.2 43.8 37.6 31.4 25.2 - -
67 57.5 2.8 55.5 48.5 42.3 36.1 29.9 - 54.3 3.2 53.3 47.1 40.9 34.7 28.5 -
62 53.7 2.8 53.7 53.7 52.3 46.1 39.9 33.7 50.0 3.2 50.0 50.0 49.3 43.1 36.9 30.7
57 51.8 2.8 51.8 51.8 51.8 45.6 39.4 33.2 49.4 3.2 49.4 49.4 49.4 43.2 37.0 30.8
95°F 105°F
1000
77 54.4 3.6 21.4 17.7 14.0 - - - 51.0 4.1 20.3 16.6 13.0 - - -
72 49.9 3.6 28.1 24.4 20.7 17.0 - - 46.8 4.1 26.9 23.2 19.5 15.9 - -
67 45.4 3.6 34.8 31.1 27.4 23.7 20.0 - 42.5 4.1 33.5 29.8 26.1 22.5 18.8 -
62 41.2 3.6 41.2 37.7 32.7 29.0 25.3 21.6 38.5 4.1 38.5 36.7 31.4 27.7 24.0 20.3
1200
77 56.1 3.6 23.9 19.6 15.3 - - - 52.5 4.1 22.7 18.4 14.2 - - -
72 51.5 3.6 31.2 27.0 22.7 18.4 - - 48.1 4.1 29.9 25.7 21.4 17.2 - -
67 46.8 3.6 38.6 34.3 30.1 25.8 21.5 - 43.8 4.1 37.1 32.9 28.7 24.4 20.2 -
62 42.5 3.6 42.5 40.2 35.9 31.6 27.4 23.1 39.6 4.1 39.6 38.4 34.4 30.2 26.0 21.7
57 43.1 3.5 43.1 43.1 38.9 34.6 30.3 26.1 40.6 4.0 40.6 40.6 36.5 32.2 28.0 23.8
1400
77 57.8 3.6 26.3 21.5 16.7 - - - 54.0 4.1 25.0 20.2 15.5 - - -
72 53.0 3.6 34.3 29.5 24.7 19.9 - - 49.5 4.1 32.8 28.1 23.3 18.6 - -
67 48.2 3.6 42.3 37.5 32.7 27.9 23.1 - 45.0 4.1 40.7 36.0 31.2 26.4 21.7 -
62 43.8 3.6 43.8 42.6 39.1 34.3 29.4 24.6 40.7 4.1 40.7 40.2 37.4 32.7 27.9 23.1
57 44.4 3.5 44.4 44.4 42.3 37.5 32.7 27.9 41.7 4.0 41.7 41.7 39.7 34.9 30.2 25.4
1600
77 59.5 3.6 28.8 23.4 18.0 - - - 55.5 4.1 27.3 22.0 16.7 - - -
72 54.6 3.6 37.4 32.1 26.7 21.3 - - 50.9 4.1 35.8 30.5 25.2 19.9 - -
67 49.6 3.6 46.1 40.7 35.3 30.0 24.6 - 46.3 4.1 44.3 39.0 33.7 28.4 23.1 -
62 45.1 3.6 45.1 45.1 42.2 36.9 31.5 26.2 41.9 4.1 41.9 41.9 40.5 35.2 29.9 24.6
57 45.7 3.6 45.7 45.7 45.7 40.4 35.0 29.6 42.9 4.0 42.9 42.9 42.9 37.6 32.3 27.0
1800
72 55.4 3.6 39.8 34.0 28.3 22.5 - - 51.5 4.1 38.2 32.5 26.8 21.0 - -
67 50.4 3.6 48.6 43.2 37.4 31.6 25.8 - 46.9 4.1 45.9 41.5 35.8 30.1 24.3 -
62 45.7 3.6 45.7 45.7 44.3 38.5 32.7 26.9 42.4 4.1 42.4 42.4 41.7 35.9 30.2 24.5
57 46.4 3.5 46.4 46.4 46.4 40.6 34.8 29.0 43.4 4.0 43.4 43.4 43.4 37.7 32.0 26.2
2000
72 56.1 3.6 42.2 36.0 29.8 23.6 - - 52.1 4.1 40.7 34.5 28.3 22.2 - -
67 51.1 3.6 51.1 45.7 39.5 33.3 27.0 - 47.4 4.1 47.4 44.0 37.9 31.7 25.6 -
62 46.4 3.6 46.4 46.4 46.4 40.1 33.9 27.7 42.9 4.1 42.9 42.9 42.9 36.7 30.6 24.4
57 47.0 3.5 47.0 47.0 47.0 40.8 34.6 28.4 43.9 4.0 43.9 43.9 43.9 37.8 31.6 25.4
