XP036-060 Physical Data
Component
Models
XP036
XP048
XP060
Nominal Tonnage
3.0
4.0
5.0
ARI COOLING PERFORMANCE
Gross Capacity @ ARI A point (Btu)
36200
48500
60100
ARI net capacity (Btu)
35000
46500
57500
EER
11.0
10.8
10.6
SEER
13.0
13.0
13.0
Nominal CFM
1200
1600
1850
System power (KW)
3.25
4.26
5.42
Refrigerant type
R-410A
R-410A
R-410A
Refrigerant charge (lb-oz)
13-0
13-0
12-10
ARI HEATING PERFORMANCE
47°F capacity rating (MBH)
34800
45000
56500
System power (KW) / COP
3.29 (kW) / 3.10
4.06 (kW) / 3.25
5.4 (kW) / 3.10
17°F capacity rating (MBH
19000
27000
34400
System power (KW) / COP
2.60 (kW) / 2.15
3.86 (kW) / 2.06
4.75 (kW) / 2.10
HSPF (Btu/Watts-hr)
7.70
7.70
7.70
DIMENSIONS (inches)
Length
82-1/4
82-1/4
82-1/4
Width
44-7/8
44-7/8
44-7/8
Height
32-5/8
32-5/8
32-5/8
OPERATING WT. (lbs.)
575
585
590
COMPRESSORS
Type
Scroll
Scroll
Scroll
Quantity
1
1
1
CONDENSER COIL DATA
Face area (Sq. Ft.)
16.88
16.88
16.88
Rows
2
2
2
Fins per inch
18
18
18
Tube diameter
3/8
3/8
3/8
Circuitry Type
Split-face
Split-face
Split-face
EVAPORATOR COIL DATA
Face area (Sq. Ft.)
5.06
5.06
5.06
Rows
4
4
4
Fins per inch
13
13
13
Tube diameter
0.375
0.375
0.375
Circuitry Type
Split-face
Split-face
Split-face
Refrigerant control
TXV
TXV
TXV
