RT-223 Appendix
ZOOM RT-223 75
COMP EQ Module
Parameter description
[Table 1 Synchronization setting for RATE and TIME parameter ]
Parameters
EFFECT
ON/OFF
MLT CMP
XOVER
L
XOVER
H
SENS
H
SENS
M
SENS
L
MIX
H
MIX
M
MIX
L
EQ
H
EQ
M
EQ
L
BASS
ON/OFF
LEVEL
Divides the signal into three frequency bands and separately sets compressor and mix for each.
Also includes 3-band equalizer.
EFFECT
ON/OFF
LO-FI
CHARA COLOR DIST TONE
EFX
LVL
DRY
LVL
EQ H EQ M EQ L
BASS
ON/OFF
LEVEL
Simulates low-fi sound. Also includes 3-band equalizer.
EFFECT
ON/OFF
RESONNC
DEPTH FREQ RATE TYPE RESO
EFX
LVL
DRY
LVL
EQ H EQ M EQ L
BASS
ON/OFF
LEVEL
Resonance filter with LFO. Also includes 3-band equalizer.
Parameter name Setting range Parameter description
EFFECT ON/OFF ON, OFF Controls effect ON/OFF for each patch.
TYPE MLT CMP, LO-FI, RESONNC Selects from three available types.
XOVER L 50 - 16000 Sets the division point for low/mid frequency bands.
XOVER H 50 - 16000 Sets the division point for mid/high frequency bands.
SENS H 0 - 24 Sets the compressor sensitivity in the high range.
SENS M 0 - 24 Sets the compressor sensitivity in the mid range.
SENS L 0 - 24 Sets the compressor sensitivity in the low range.
MIX H 0FF, -24 - 6 Sets the high range mix amount.
MIX M 0FF, -24 - 6 Sets the mid range mix amount.
MIX L 0FF, -24 - 6 Sets the low range mix amount.
CHARA 0 - 10 Sets the filter characteristic.
COLOR 1 - 10 Adjusts the sound color.
DIST 0 - 10 Adjusts the distortion.
TONE 0 - 10 Adjusts the tonal quality.
DEPTH 0 - 10 Sets the effect depth.
FREQ 1 - 30 Sets the LFO offset.
RATE 1 - 30, t0 - t9, M1 - M4
Sets the effect rate. When set to "tx" or "Mx", rate is synchronized to
rhythm tempo (see Table 2).
TYPE HPF, LPF, bPF Selects the filter type.
RESO 1 - 30 Applies resonance to the effect.
EFX LVL 0 - 30 Sets the effect sound mix amount.
DRY LVL 0 - 30 Sets the original sound mix amount.
EQ H -12 - 12 Applies boost/cut to the high range.
EQ M -12 - 12 Applies boost/cut to the mid range.
EQ L -12 - 12 Applies boost/cut to the low range.
BASS ON/OFF ON, OFF Switches bass effect processing ON/OFF.
LEVEL 1 - 30 Sets the patch output level.
Setting value Frequency Setting value Frequency Setting value Frequency
t0 Thirty-second note t5 Half note triplet M1 Full note
t1 Sixteenth note t6 Dotted eighth note M2 Full note x 2
t2 Quarter note triplet t7 Quarter note M3 Full note x 3
t3 Dotted sixteenth note t8 Dotted quarter note M4 Full note x 4
t4 Eighth note t9 Half note
