RT-223 Appendix

ZOOM RT-223

74

Reverb Module

Parameter description

Parameters

EFFECT
ON/OFF

HALL

PRE DLY

DECAY

EQ H

EQ L

DAMP

E/R MIX

DR SEND BS SEND KICKDRY

EFX LVL

Produces concert hall type reverberation.

EFFECT
ON/OFF

ROOM

PRE DLY

DECAY

EQ H

EQ L

DAMP

E/R MIX

DR SEND BS SEND KICKDRY

EFX LVL

Produces room type reverberation.

EFFECT
ON/OFF

SPRING

PRE DLY

DECAY

EQ H

EQ L

DAMP

KICKDRY BS SEND KICKDRY

EFX LVL

Simulates a spring reverb.

EFFECT
ON/OFF

PLATE

PRE DLY

DECAY

EQ H

EQ L

DAMP

KICKDRY BS SEND KICKDRY

EFX LVL

Simulates a plate reverb.

EFFECT
ON/OFF

DELAY

TIME

FB

DAMP

PAN

KICKDRY BS SEND KICKDRY

EFX LVL

Delay with up to 700 ms delay time.

EFFECT
ON/OFF

CHORUS

LFO TYP

DEPTH

RATE

PRE DLY KICKDRY BS SEND KICKDRY

EFX LVL

Adds modulation and spread.

EFFECT
ON/OFF

FLANGER

DEPTH

RATE

FB

LFO SFT KICKDRY BS SEND KICKDRY

EFX LVL

Adds an undulating sound with strong character.

Parameter name

Setting range

Parameter description

EFFECT ON/OFF

ON, OFF

Controls effect ON/OFF for each patch.

TYPE

HALL, ROOM , SPRING, PLATE, DELAY,
CHORUS, FLANGER

Selects from seven available types.

LFO TYP

Mn, St

Sets LFO phase to Mn (Mono) or St (Stereo).

LFO SFT

0 - 180

Sets the left/right phase difference.

DEPTH

0 - 10

Sets the effect depth.

RATE

CHORUS : 1 - 30

Sets the effect rate. When set to "tx" or "Mx", rate is
synchronized to rhythm tempo (see next page Table 1).

FLANGER : 1 - 30, t0 - t9, M1 - M4

PRE DLY

CHORUS : 1 - 30

Sets the predelay.

HALL, ROOM, SPRING, PLATE : 1 - 100

TIME

1 - 700, t0 - t7

Sets the delay time in 1-ms steps. When set to "tx", delay time
is synchronized to rhythm tempo (see next page Table 1).

FB

DELAY : 0 - 10

Sets the feedback amount.

FLANGER : -10 - 10

DAMP

0 - 10

Sets the high-range attenuation of the reverb sound and delay
sound.

PAN

L10 - L1, 0, r1 - r10

Sets the stereo position of the delay sound.

DECAY

1 - 30

Sets the reverb time.

EQ H

-12 - 6

Controls the high-range level of the effect sound.

EQ L

-12 - 6

Controls the low-range level of the effect sound.

E/R MIX

0 - 30

Sets the level of the initial reflection.

KICKDRY

ON, OFF

Switches KICK (bass drum) effect processing for pad 0 ON/
OFF.

DR SEND

0 - 100

Adjusts the drum effect sound send level.

BS SEND

0 - 100

Adjusts the bass effect sound send level.

EFX LVL

0 - 30

Sets the effect sound mix amount.
