54 Z4Mplus/Z6Mplus User Guide 13163L Rev. 3 5/20/2004
Configuration
Basic Configuration
Adjust Tear-Off Position
The Tear-Off position defines the position of the label on the tear-off bar. When working with
non-continuous labels, the inter-label gap should be on the tear bar. This setting does not apply
to continuous media.
4. Are you using continuous media?
5. Does the inter-label gap line up on the tear bar?
Select Print Mode
When the wrong Print Mode is selected, the top of the label is not found by the printer.
Examples of common problems include when the gaps between noncontinuous labels do not
line up on the tear bar or when continuous media is not being cut at the right interval.
6. Do the labels line up or cut correctly?
If... Then...
Yes 1. Press PLUS (+) to move to the next option: PRINT MODE .
2. Continue with Select Print Mode .
No 1. Continue with Step 5 .
If... Then...
Yes 1. Press PLUS (+) to move to the next option: PRINT MODE .
2. Continue with Select Print Mode .
No 1. Press SELECT.
2. Press PLUS (+) to move the label forward or MINUS (–) to move the
label backward. Repeat this until the label lines up correctly.
3. Press SELECT to accept the changes.
4. Press PLUS (+) to move to the next option.
PRINT MODE displays. Continue with Select Print Mode .
If... Then...
Yes 1. Press PLUS (+) to move to the next option: MEDIA TYPE .
2. Continue with Select Media Type .
No Review the media and the printer options, then complete the following steps:
1. Press SELECT.
2. Press PLUS (+) or MINUS (–) to scroll through the setting options. Stop
at the setting that matches your printer options (Tear-Off, Peel-Off, Cutter,
or Rewind).
3. Press SELECT to accept the change.
4. Press PLUS (+) to move to the next option.
MEDIA TYPE displays. Continue with Select Media Type .
