Printer Operation
Load Fanfold Media
13163L Rev. 3 5/20/2004 Z4Mplus/Z6Mplus User Guide 39
To load fanfold media, complete these steps:
1. Press the printhead open lever. The printhead assembly springs up.
2. Flip down the media supply guide.
3. Slide the media guide as far from the main frame as possible.
4. Pass the fanfold media over the media supply hanger.
5. Flip up the media supply guide. Slide in the media supply guide until it just touches, but
does not restrict, the edge of the media.
6. Thread the media under the dancer, through the slot in the transmissive sensor, under the
ribbon sensor, and out the front of the printer.
7. Ensure the media is against the back of the transmissive sensor. Then, slide in the media
guide until it just touches, but does not restrict, the edge of the media.
8. Close the printhead assembly.
9. Press PAUSE.
Caution • Ensure that the printhead is fully open and engaged in the upright position.
If you fail to latch the printhead, it could fall on your hand during the procedure.
