Installation
3–20 445-0089-01-01
Step 8: Mounting the Display Panel
The communications cable supplied with the display panel is 70 feet long (21
meters). If you want to replace the cable with one that is longer or shorter, use a
high quality, 6-wire telephone extension cable. You can install the panel up to 100
feet (30 meters) away from the PROsine.
Flush mounting the panel on a wall, bulkhead, or panel requires an opening that is
approximately 4 inches x 4 inches (10cm x 10cm). About 1 1/4 inches (3cm) of
free space is required within the wall to accommodate the depth of the panel. Be
sure there is no wiring or other obstructions within the wall before you make an
opening.
To mount the display panel:
1. Choose a location that is dry, out of direct sunlight, free from corrosive or
explosive fumes, and otherwise appropriate for mounting an electronic
device.
2. Tape the mounting template (in the PROsine package) to the mounting surface
and mark the locations of the mounting holes and the area to be cut away.
3. Pilot-drill the mounting holes and cut out the hole in which the panel will be
inserted.
4. Route the communications cable(s) inside the wall and through the opening.
5. Insert one of the cable’s connectors in either jack on the bottom of the panel.
6. Place the panel in the opening and secure it with appropriate fasteners.
7. Route the communications cable to the PROsine and insert the connector in
the jack labelled DISPLAY.
