Specifications

A–4

445-0089-01-01

Environmental Specifications

System

Regulatory Approvals

Ambient Temperature:

Operating Temperature Range
Storage Temperature Range

–20–60ºC, with output derated above 40

°

C

–40–70ºC

Humidity: Operation/Storage

5–95% RH, non-condensing

Transfer relay rating

30A, 1.5hp

Transfer time

16ms

Transfer on bad voltage

85–110V for low AC and 120–135 for high AC,
user-adjustable.

Transfer on bad frequency

40–70Hz user-adjustable for high and low
frequency limits.

Inverter synchronized to line before
transfer

Yes

Remote ON/OFF

An isolated input to the unit where, with 5–18V
applied the unit operates normally, with <1V the
unit is off.

Cooling

Fan, activated by any of the following:
High internal temperature
High AC input current
High AC output current

CSA/NRTL approved to CSA 107.1, UL458 (including Marine Supplement), and UL1741

Complies with ABYC recommended practices E-8, E-9, A-20, and A-25 for marine use

Compliance to KKK-A-1822D for use in “Star-of-Life” ambulances available on request
