Display Panel Features

445-0089-01-01

2–9

CHARGER Switch

This switch is active in all Display modes: ON, OFF, CONFIGURE.

CHARGER LEDs

The LEDs are continuously updated whenever the Display Mode switch is set to
ON or CONFIGURE.

Switch Position

Description

ENABLE

The charger is enabled and will charge the battery according to
the way the unit is configured if shorepower is “good.”

DISABLE

The charger is off and will consume minimal power.

LED

Description

STANDBY

and

STANDBY
LED Status

CHARGING
LED Status

OFF

OFF

The charger is not running because it is not enabled, the charge
cycle has been completed, or a system error has occurred.

OFF

ON

The charger is running.

CHARGING

ON

OFF

The charger is enabled but is not running because shorepower
is not “good.”

EQUALIZE

OFF

Equalize mode has not been selected.

ON

The charger is in Equalize mode and the batteries are charging.

CAUTION:

Battery voltage may go up to 17V.

FLASHING

Equalize mode has been selected; the charger is presently
executing the basic charge cycle in preparation for
Equalization mode. (The CHARGING LED is also on in this
stage.)

READY

OFF

The charger is not running, or the Charge cycle is not finished.

ON

The Charge cycle is complete. The battery is fully charged.
