Xerox 16 Series User Manual
Page 91
Cleaning the Punch
4-7
4
Figure 4-3: The Side Guide and Infeed Guide
6
Remove and clean the Output Guide Roller assembly and the red rollers
under the Output Guide Roller assembly. Clean the rollers with
Isopropyl alcohol and a clean lint-free cloth. Check also for
accumulations of paper dust or toner on the base plate.
7
Close (lower) all assemblies and reinstall the Output Guide Roller
assembly when finished. Close the Top Covers and resume normal
operation.
Teflon® is a registered trademark of E.I. du Pont de Nemours and Company.
Infeed Guide
(Teflon® Plastic
Piece)
Side Guide
