About the FusionPunch II 1-5
1
Specifications
Printer DocuTech 135, 6100, 6115, 6135, 6155 and 6180.
DocuPrint 4050, 4090, 4135, 4180, 4635, 4850 and 4890.
Supported Sheet Size Productivity
Punching Long Edge
8.5 x 11/A4
All printers run at the rated speed of the printer.
(Including Index Tabs and 9" Covers)
Punching Short Edge
(*) 8.5 x 11/A4
All printers run at the rated speed of the printer
except for the DT 6180. (DT 6180 is slightly slower due to
a skip pitch introduced in the printer.)
(*) 8.5 x 14 All printers run at the rated speed of the printer
except for the DT 6180. (DT 6180 is slightly slower due to
a skip pitch introduced in the printer.)
(#) 11 x 14 All printers run at the rated speed of the printer
except for the DT 6180. (DT 6180 is slightly slower due to
a skip pitch introduced in the printer.)
(#) 11 x 17/A3 All printers run at the rated speed of the printer.
Denotations:
(*)
Requires a GBC Bypass Stacker and a Xerox High
Capacity Stacker.
(#) Requires a GBC Stacker without the Bypass or a GBC
Bypass Stacker and a Xerox High Capacity Stacker.
Paper Stock 60 gsm Bond to 200 gsm Index.
Output Stacker Each stacker holds 2500 sheets.
Dimensions 81 inches (2058 mm) L x 32 inches (813 mm) W x 56
inches (1422 mm) H.
Weight Punch: 620 lbs. (281 kg.)
Stacker: 270 lbs. (123 kg.)
Bypass Stacker: 320 lbs. (145 kg.)
Power Supply USA/Canada - Punch: 115 VAC, 60 Hz, 4.7 amps.
Stacker: 115 VAC, 60 Hz, 1.0 amps.
International - Punch: 230 VAC, 50 Hz, 6.8 amps.
Stacker: 230 VAC, 50 Hz, 0.25 amps.
Temperature Range 41 - 104 Degrees F. (5 - 40 Degrees C.)
Humidity Range 30% - 95%, non-condensing.
Altitude 3280 feet (1000 meters).
