Personality Profiles A-17
A
With the Xerox SBM2 downstream
DocuTech 61XX to FusionPunch II to SBM2 –
without CIM
Device Profile - Properties and Default Limits Tab
Paper Sizes
Set Sizes
Non-Stream Feed /
Stream Feed
8.5x11/8.5x14/A4
1 to 22 Sheet Set
Non-Stream Feed
8.5x11/8.5x14/A4
1 to 22 Sheet Set
Stream Feed
8.5x11/8.5x14/A4
23 to 27 Sheet Set
Non-Stream Feed
Device Name SBM2Bk1to22 SBM2Bk1to22S SBM2Bk23to27
Type External External External
Function 1 Line Off Line Off Line Off
Function 2 Line Off Line Off Line Off
Sheet Sequence 1-N and N-1 1-N and N-1 1-N and N-1
Side 1 Direction Face Up
and
Face Down
Face Up
and
Face Down
Face Up
and
Face Down
Rotate Always Always Always
Minimum Sheet
Length
254 254 254
Maximum Sheet
Length
364 364 364
Minimum Sheet
Width
203 203 203
Maximum Sheet
Width
432 432 432
Minimum Sheet
Weight
60 60 60
Maximum Sheet
Weight
200 200 200
Minimum Set Size 1 1 23
Maximum Set 22 22 27
