Xerox 16 Series - Manual (Page 118)

A-24 Appendix A
D ocuTech 61X X to FusionPunch II to
SBM 2 - w ith C IM
Device Profile - Properties and Default Limits –
Timings Tab
(*) = For E ach H igh C apac ity S tacker on a D T 6155 / 6180, A dd 656m s To S heet
and S et Jam Tim es.
(*) = For E ach H igh C apac ity S tacker on a D T6100 /6115 / D T6135, A dd 861m s To S heet
and S et Jam Tim es.
(#) = For E ach H igh C apac ity Stacker A dd 50m s To E nd of S et O ffset.
D ocuTech M odel
P aper S izes
S et S izes
N on-S tream Feed /
S tream Feed
D T 6155 / 6180
8.5x11/8.5x14/A 4
1 to 27 S heet S et
S tream Feed
D T 6155 / 6180
11x17/A 3
1 to 27 S heet S et
N on-S tream Feed /
S tream Feed
Tim e B etween S heets 120 120
S heet Jam Tim e (*) 800 (*) 800 (*)
S et C om piler P rocessing
Tim e
400 600
M axim um S et P rocessing
Tim e
1200 2400
S et Jam Tim e (*) 7168 (*) 7168 (*)
Tim e to C ycle U p 0 0
S 0 E nabled E nabled
S 1 E nabled E nabled
S 2 E nabled E nabled
S 3 D isabled D isabled
S 4 D isabled D isabled
D elivery S ignal Type Lead E dge Lead E dge
D elivery S tart A djust 0 0
D elivery E nd A djust 50 50
E nd of S et Offset (#) 250 (#) 90 (#)
R ecovery B ehavior S E T S E T
Finisher C apacity 7 7
C ycle D own D elay 0 0
