User’s Manual 4-29
Operating Basics
Open dialog box, if the modem and Telephony Current
Location region code do not match.
A warning dialog box is displayed if current settings for region code and
telephony location are incorrect.
Modem Selection
If the computer cannot recognize the internal modem, a dialog box is
displayed. Select the COM port for your modem to use.
Dialing Properties
Select this item to display the dialing properties.
Attaching the ferrite core to the modular cable
The ferrite core that attaches to the modular cable bundled with this product
is explained here. When connecting the modular cable, attaching the
bundled ferrite core to the modular cable will help to reduce noise.
To attach the ferrite core, follow the steps below.
1. Free the lock and the ferrite core is opened.
Figure 4-10 Opening the ferrite core
2. Adjust the modular cable so that it falls in the center dimple of the ferrite
core.
Please ensure that the connector of modular cable and the ferrite core
are placed around 30mm apart.
Figure 4-11 Opening the ferrite core
If you are using the computer in Japan, the Telecommunications Business
Law requires that you select Japan region mode. It is illegal to use the
modem in Japan with any other selection.
Lock
Ferrite core
