User’s Manual 2-7
The Grand Tour
Front with the display open
This section shows the front of the computer with the LCD display panel
open. Refer to the appropriate illustration for details. To open the LCD
display panel, simply lift it up at its front edge. Position the LCD display
panel at a comfortable viewing angle.
Figure 2-6 The front of the computer with the LCD panel open
Notches Notches on the computer engage hooks on the
libretto docking device to ensure a secure
connection.
Memory module
cover
This cover protects one memory module socket.
Depending on the configuration of the computer
either one or no module is preinstalled. Refer to
the Memory expansion section in Chapter 8,
Optional Devices .
LCD screen
AccuPoint control buttons
Power button
Display hinge
AccuPoint
Fingerprint
Sensor
LCD Sensor switch
(Not shown)
Stereo speaker
(Left)
Stereo speaker (Right)
