User’s Manual 8-7
Optional Devices
Installing memory module
Follow the steps below to install a memory module.
1. Set the computer to boot mode and turn the computer’s power off.
Make sure the Power indicator is off. Refer to the Turning off the power
section in Chapter 3, Getting Started.
2. Remove AC adaptor and all cables connected to the computer.
3. Turn the computer upside down and remove the battery pack. Refer to
Replacing the battery pack section in Chapter 6, Power and Power-Up
Modes, for details.
4. Loosen the screw securing the memory module cover. The screw is
attached to the cover to prevent it from being lost.
5. Slide your fingernail or a thin object under the cover and lift it off.
Figure 8-5 Removing the memory module cover
6. Align the notch of the memory module with that of the memory slot,
gently insert the module into the slot at about a 45 degree angle and
push the module down until latches on either side snap into place.
Figure 8-6 Seating the memory module
Memory module cover
Screw
