2-4 User’s Manual
The Grand Tour
Right side
Figure 2-3 shows the computer’s right side.
Figure 2-3 The right side of the computer
Volume control
LAN jack
Headphone jack
USB ports
Modem jack
Microphone jack
Volume control Use this dial to adjust the volume of the stereo
speakers and the stereo headphones.
Headphone jack A 3.5 mm mini headphone jack enables
connection of stereo headphones.
Microphone jack A 3.5 mm mini microphone jack enables
connection of a three-conductor mini jack for
monaural microphone input.
Universal Serial Bus
(USB 2.0) port
Two Universal Serial Bus ports are on the right
side. The ports comply with the USB 2.0
standard, which enables data transfer speeds
40 times faster than the USB 1.1 standard
(The ports also support USB 1.1).
Keep foreign objects out of the USB connectors. Never allow metal
objects, such as screws, staples and paper clips, to enter the PC or
keyboard. Foreign metal objects can create a short circuit, which can
cause PC damage and fire, possibly resulting in serious injury.
Operation of all functions of all USB devices has not been confirmed.
Some functions might not execute properly.
Modem jack In areas where an internal modem is installed as
standard equipment, there is a modem jack that
lets you use a modular cable to connect the
modem directly to a telephone line.
