Toshiba e310 - Manual

TOSHIBA
Toshiba Pocket PC e310
e310:
StrongArm 206MHz/3.5”, 240x320 TFT/32MB(ROM)-32MB(RAM)/SD/Windows Pocket PC 2002
Product Hightlights
• Value-priced, the Toshiba Pocket PC e310 is the best-suited
productivity companion for customers who require additional
expansion and multimedia features in their handheld device
• Combining simplicity and ease of use, the Toshiba Pocket PC
e310 features familiar business applications such as Microsoft®
Word and Excel, handwriting recognition and enhanced sync
capabilities for seamless data transfer
• With an integrated Secure Digital™ (SD) media slot, Toshiba
Pocket PC e310 users can take advantage of expanded memory
capabilities as well as play MP3 and MPEG 4 files and store their
favorite digital images
• Packaged in an attractive and sleek, lightweight silver chassis,
the Toshiba Pocket PC e310 integrates a bright, 64K color display
for easy readability both indoors and outdoors
• The Toshiba Pocket PC e310 builds upon the mobile computing
leadership of Toshiba focusing on developing the best mobile
solutions to solve real customer needs
System Characteristics
Processor
• Intel® StrongArm® 206MHz processor
Memory
• Main memory: 32MB SDRAM; 3.3V
• Program memory: 32MB CMOS Flash ROM
Display
• 3.5” TFT color reflective display; 240 x 320 (portrait) resolution
(16 bit)
• Front light fluorescent lamp
• 65,536 (64K) colors; 5 step Brightness control (by Software)
• MediaQ Graphics Controller; 256KB internal video memory
Input Devices
• Touch Panel: Analog resistance sensitive system touch panel;
1024 x 1024 dots
• Controls/Buttons: 5-way navigation button; 4 application keys-
Calendar, Contacts, Task, Menu; 3 function navigator (Toshiba
Scroller) for Up, Down and Action; Reset switch; Voice record
button; Power on/off button; Battery on/off switch, Stylus pen
Expandability
• 1 SD (Secure Digital) card slot (3.3V)
Ports
• Universal Serial Bus port – (Client)
• SIR IrDA Infrared port (115kbps)
• DC-in
• Cradle connector port (26 pins)
• Stereo headphone port
Physical Description
• Dimensions (LxWxH): 4.9” x 3.1” x 0.4”
• Weight: 4.9oz (w/Stylus & battery)
• LED Indicators: One 2 color (Green, Orange) LED for Power
Indication:
1.
Green: Full Charge (while power source is AC adaptor)
2. Orange: Charging (while power source is AC adaptor)
3. Orange Flash: Alarm
4. Yellow (Green and Orange): Out of Temperature
5. Off: Power on/off
• User Power on Password
Sound
• I2S Codec Chip; ADS7846 Sound Chip
• 16-bit stereo; 8.0, 11.025, 22.05 and 44.1KHz Sample Rate
• Full Duplex Record and Playback
• Software Volume Control
• Built-in Microphone and Built-in Speaker
• Stereo Headphone jack
Power Supply
• AC Adapter: 5V/2A DC output; 100-240V input voltage, 50/60Hz
frequency
• Battery Pack: Rechargeable Advanced Lithium-Ion (Li-Ion)
battery; 3.7V / 1000 mAh
• Battery Saver: Stand by; Display Auto Off
Battery life may vary depending on applications, power management
settings and features utilized. Recharge time varies depending on usage.
Operating System
• Microsoft  Windows Pocket PC 2002
Additional Software
• Pocket Word
• Pocket Excel
• Pocket Outlook
• Pocket Internet Explorer
• Microsoft® Reader
• Media Player 8 for Pocket PC
• File Explorer
• MSN Messenger
• Microsoft® Transcriber
• Microsoft® Active Sync 3.5
• Microsoft® Outlook 2002
• Adobe Acrobat® Reader® for Pocket PC
Warranty
• 1 year parts, labor and battery
• 90 days for software
Environmental Specifications
• Temperature: Operating: 0 ° to 40°C (32° to 104°F); Non-
operating: -20 ° to 65°C (-4° to 149°F)
• Relative Humidity: Operating: 10% to 90% non-condensing
• Altitude (relative to sea level):
Operating: 10,000ft (4hrs with 0°C); Altitude change rate: 2000ft/min.
Non-operating: 40,000ft (4hrs with 0°C); Altitude change rate: 2000ft/min.
• Thermal Shock: -35°C to 60°C, 10 to 30 cycles
• Vibration: Operating: 1.0G; Non-operating: 1.5G
Accessories
USB Client Cable PA3185U-1ETC
10W AC Adapter PA3183U-1ACA
USB Cradle PA3186U-1DST
Stylus Pen (3-pack) PA3182U-1ETC
Bluetooth SD (Secure Digital) Card
PA3172U-1BTM
Leather Case PA1301U-1PCS
Screen Overlays PA1302U-1PMS
Product/Part Numbers/UPC
Pocket PC e310 PA3169U-1P05
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without
notice. Copyright 2002 TAIS pda_e310.doc Rev. 4 4/4/2002
