030-300198 Rev. D 73 March 2003
WireSpeed Dual Connect NAT Router User Guide
Service Name
The NAT service you selected.
Local IP Address If a static IP address has been assigned, it will be displayed here.
Global Port Range The Global Port Range will be mapped to host the device beginning at the base host
port. The port range that is provided by the service that you are customizing.
Acceptable values for Global Port Range are 1 to 65535, and the first port must be
less than or equal to the second port.
Base Host Port The port on the WAN that will host the NAT service selected. Acceptable values for
Base Host Port are 0 to 65535, and the first port must be less than or equal to the
second port.
Protocol The type of Protocol that is used to run this NAT service.
TCP- Transmission Control Protocol.
UDP-User Datagram Protocol (UDP).
Port Forwarding Trigger Ports
To select Port Forwarding Trigger Ports, click on define custom service from the Service Configuration screen
and then select Trigger Ports from the Custom Service screen. Click on next. The follow settings will be displayed
in the Trigger Ports screen. Enter your values in the Local ‘Trigger’ Port Range fields and click on next to
continue.
Service Name
The NAT service you selected.
Local Trigger Port Range The local LAN side TCP/UDP port. Acceptable values for Local Trigger Port Range
are 1 to 65535, and the first port must be less than or equal to the second port.
Global Port Range The WAN side TCP/UDP port range. Acceptable values for Global Port Range are
1 to 65535, and the first port must be less than or equal to the second port.
