030-300198 Rev. D 5 March 2003
WireSpeed Dual Connect NAT Router User Guide
5. INSTALLATION INFORMATION
5.1 Installation
Requirements
To install the Dual Connect Router, you will need the following:
• A Network Interface Card (NIC) installed in your PC or
• An available USB port installed on your PC.
• A DSL-ready line (provided by your Service Provider).
NOTE: Please wait until you have received notification from your service provider that your DSL line has been
activated before installing this Router and software.
5.2 Before you begin:
Make sure that your kit contains the following items:
• Westell WireSpeed Dual Connect NAT Router
• Power Supply
• RJ-45 Ethernet cable (straight-through)
• USB cable
• RJ-11 Phone cable
• Westell CD-ROM containing USB software drivers
and User Guide in PDF format
• Quick Start Guide
5.3 Microfilters
ADSL signals must be blocked from reaching each telephone, answering machine, fax machine, computer modem
or any similar conventional device. Failure to do so may degrade telephone voice quality and ADSL performance.
Install a microfilter if you desire to use the DSL-equipped line jack for telephone, answering machine, fax machine
or other telephone device connections. Microfilter installation requires no tools or telephone rewiring. Just unplug
the telephone device from the baseboard or wall mount, and plug in a microfilter. Next, plug in the telephone device.
Contact Westell to obtain a microfilter kit, which contains multiple microfilters for your installation.
5.4 Router Installations
This section explains the procedures for installing Westell’s Dual Connect Router via 10/100 Base-T/Ethernet or
USB connection.
NOTE: This product supports simultaneous use of Ethernet and USB ports. Please wait until you
have received notification from your Service Provider that your DSL line has been activated before
installing your Dual Connect Router. See section 5.4.3 for instructions on simultaneous hardware
(Ethernet and USB) installation.
