030-300198 Rev. D 48 March 2003
WireSpeed Dual Connect NAT Router User Guide
DHCP Configuration
The following settings will be displayed if you select DHCP Configuration from the Configuration menu.
DHCP Server
This setting allows the ADSL router to automatically assign IP addresses to
local devices connected on the LAN. Westell advises setting this to enabled for
the private LAN.
Off = DHCP Server is disabled
Private LAN = DHCP addresses will be saved into the Private LAN
configuration.
Public LAN = DHCP addresses will be saved into the Public LAN
configuration. This option is only available if the Public LAN DHCP server is
enabled.
NOTE: If you enable Public LAN, you must enter your values in the fields.
Your Internet service provider may support dynamic setting of the Private
LAN values, however, IP assignment will not overwrite the default Private
LAN values.
DHCP Start Address Factory Default = 192.168.1.15
This field displays the first IP address that the DHCP server will provide. The
DHCP Start Address must be within the IP address and lower than the DHCP
End Address. You may use any number from 0 to 254 in this address.
DHCP End Address Factory Default = 192.168.1.47
This field displays the last IP address that the DHCP server will provide. The
DHCP End Address must be within the IP address and higher than the DHCP
Start Address. You may use any number from 0 to 254 in this address.
The actual information displayed in this screen may vary.
