9.2.2 Warning Data Screen
These screens appear when a warning has occurred. Up to 10 screens can be displayed.
Figure 9.4 and Table 9.2 show an example of this type of screen and describe the data
shown in the screen.
Figure 9.4 Sample Warning Data Screen
Table 9.2 Warning Data Screen Descriptions
No. Name Description
c No. The number of the message in the order that it was detected (1 - 10).
(Up to 10 screens of warning data can be displayed.)
d Warning
Message Shows the nature of the warning. For details, see Section 9.2.3
"Failure Messages".
e Time The date and time (in 24-hour time) that the warning was detected.
f Scroll indicator Indicates whether there is a warning screen before or after this screen.
•
↑ indicates there is a warning screen before this screen.
•
↓ indicates there is a warning screen after this screen.
•
↑↓ indicates there are warning screens both before and after this
screen.
WARNING
1 72B MIS OPE
98-09-09 08:05:30
↓ANOTHER ITEM
c d
e
f
