Table 7.2 Normal Display Screen (continued)
5 Measurement screen
(Example) Output frequency
Shows the output frequency.
6 Measurement screen
(Example) AC input
Shows the frequency and voltage values for AC
input.
7 Measurement screen
(Example) Bypass input
Shows the frequency and voltage values for
bypass input.
8 Measurement screen
(Example) DC value
Shows the DC voltage and DC current.
For the current value, "-" indicates charging and
the absence of a plus/minus sign indicates
discharging.
9 Measurement screen
(Example) Counter value
Shows the total time of UPS operation and the
number of times the battery has been operated
and total time for battery use (the time AC input
has been off).
O/P FREQUENCY
FREQ. 60.0[Hz]
AC INPUT
AC I/P-V 200[V]
FREQ. 60.0[Hz]
BYPASS INPUT
BYP I/P-V 200[V]
FREQ. 60.0[Hz]
DC INPUT
DC-V 401[V]
BATT-V 401[V]
BATT- I 0[A]
MODE COUNT
UPS 17544[H]
BATTERY
32[MIN]
0[TIM]
