- 23 -
6 F 3 H 1 0 0 1
7.2.2 Failure Display Screen
The Failure Display screen indicates the presence or absence of failure data and displays
that data if present.
Table 7.3 Failure Display Screen
LCD Screen Description
Presence or absence of failure data This screen indicates the presence or absence of
failure data.
This screen is displayed if there is no failure data,
or if all failure data has been reset with the "fault
display rest" key.
Failure data The failure data, the time the failure occurred, and
an indication as to whether or not there is any
other failure data is displayed with this screen if a
failure occurs.
When there is other failure data, that other data
can be displayed using the △ ▽ scroll keys.
* If there is failure data, that data will remain in the system, even after the actual cause of the
failure has been resolved, until the failure display reset key on the front of the panel is
pressed and held down for at least 5 seconds. Note that the failure data is not deleted when
the unit is turned off.
7.2.3 Warning Data Display Screen
The Warning Data Display screen indicates the presence or absence of warning data and
displays that data if present.
Table 7.4 Warning Data Display Screen
LCD Screen Description
Presence or absence of warning data This screen indicates the presence or absence of
warning data.
This screen is displayed if there is no warning
data, or if all warning data has been reset with the
"fault display reset" key.
Warning date The warning data, the time the warning occurred,
and an indication as to whether or not there is any
other warning data is displayed with this screen if
a warning occurs.
When there is other warning data, that other data
can be displayed using the △ ▽ scroll keys.
FAULT
NO FAULT INFORMATION
FAULT
1 52R TRIP
98-09-09 08:05:30
↓ANOTHER ITEM
WARNING
1 72B MIS OPE
98-09-09 08:05:30
↓ANOTHER ITEM
WARNING
NO ALARM INFORMATION
