2 lcd display – Toshiba TOSNIC-7000S User Manual
Page 21
- 20 -
6 F 3 H 1 0 0 1
7.2 LCD
Display
The LCD Display screens consist of the following screens.
(1) Normal Display screen ............. Initial display, operation guidance, and measurement
value display
(2) Failure Data Display screen ..... Displays detailed data when a failure occurs.
(3) Warning Data Display screen ... Displays detailed data when a warning occurs.
The operator can switch between these screens by pressing the scroll keys.
Normal Display screen
Failure Data
Display screen
Warning Data
Display screen
: Scroll up
: Scroll down
