- 9 -
Figure 2-2 Storing the Transporter Locking Screw for later use
2.2 SCSI Cable Connections
CAUTION
Before starting the installation of this device, be certain to
unplug the power plug of the server, workstation, or other
processing equipment. Working on the unit while the power
plug is left connected to the power outlet could result in
electrical shock.
The Autoloader is connected to the server/workstation (or other SCSI device) with a SCSI cable.
The SCSI connector of the Autoloader is located on the rear panel.
Figure 2-3 SCSI Cable Connections
To the next SCSI device
Terminator
From the host computer
