Document
imaging camera
OVERLAY
CAMERA
ARM LIGHT
LOCK
W.BALANCE
CAMERA
GAIN
6
7
CAMERA
GAIN
6
Press CAMERA GAIN (+/-) to improve view
of a camera subject which is too dark or vivid.
When finished, turn off the light and close it,
and put back the arm.
Follow the steps of "Preparation of the document imaging
camera" in reverse.
• You can adjust the "Sharpness" of the camera image on the menu screen.
• If the image flickers due to a fluorescent light in the room, either turn off the fluorescent light
or set the "Shutter" from the menu screen.
Note that the image may still flicker due to the lighting, the document status, the image
adjustment, etc., even if the "Shutter" setting is changed.
• Though this projector uses a 1.45 million pixel camera unit, the images projected on the
screen are 1024 x 768 dot images. If the "Screen size" in the menu screen is set to
"Full" the camera's full image is compressed to 1024 x 768 dots. If "Thru" is selected, the
1024 x 768 dots at the center of the image are projected.
• The light turns off automatically when the arm is leaned.
• When the arm is not raised up, the camera source cannot be projected.
• In the camera input selected, audio signals are not output.
Picture projection with the document imaging camera (continued)
Camera control panel
Notes
