Names of each part on the main unit – Toshiba TLP780U User Manual
Page 11
11
Before use
Right side
Rear side
Left side
Front side
Control panel
Air exhaust
Lens cover
Lens
Infrared remote sensor
Anti-theft lock
hole
Speaker
Air intake
Foot adjuster release button
Foot adjuster
Zooming lever
Focusing ring
Air intake
Carrying handle
Open to carry the projector.
AC IN socket
• The air exhaust discharges high temperature air. Do not put something around the air exhaust, otherwise it may be deformed by the high temperature air.
Names of each part on the main unit
CAUTION
Openings in the cabinet are provided for ventilation and
to ensure reliable operation of the product and to protect
it from overheating, and these openings must not be
blocked or covered.
Continued
The explanation here is only for the model not with the document imaging
camera. For the model with the document imaging camera, refer to .
