Projector operation control by a computer, 26 installation and connection, Remove the cover when using the control connector – Toshiba TLP780U User Manual
Page 26
26
Installation and
connection
USB
COMPUTER IN 1
COMPUTER IN 2
S-VIDEO
VIDEO
VIDEO IN
R - AUDIO - L
AUDIO
IN
( Y/P
B
/P
R
)
MONITOR
OUT
CONTROL
Note
Remove the cover when using the CONTROL connector.
Projector operation control by a computer
You can control the projector by a computer connected with the control cable supplied.
Check that the power for the projector and computer is off before connecting the cables.
To CONTROL connector
Be sure to connect in the
proper direction.
Control cable
(Supplied)
Computer
To RS-232C port
• Do not connect a cable other than the exclusive one supplied.
To remove the cover, slide it up while pushing it.
