background image

Specifications


Page 54

AirborneDirect™ Ethernet Bridge User's Guide

100-8007-141G

Quatech, Inc. Confidential

Ethernet Interface – Heavy-Duty package

Interface:

Ethernet 10Base-T

Connector:

Deutsch DTM-06-12SSA

Data Rates:

10 Mb/sec

Pin Assignments:

Pin

No.

Name

Description

1 TXTP+

Transmit+

2

RXTP+

Receive+

3 NC

No

Connect

4

NC

No Connect

5

ON/IGN

Device power OBN. Active High (internal
pull-down).

Default ON

Pulling signal LOW shuts off the internal
power supply.

6

VBAT

Battery Power Input

7 GND

Ground

8

/F_RESET

Factory RESET. Active LOW (internal
pull-up).

Default OFF

Pulling signal low as power is applied will
RESET device settings to factory default
values.

9 NC

No

Connect

10

NC

No Connect

11 RXTP-

Receive-

12

TXTP-

Transmit-
