Hardware Installation


100-8007-141G AirborneDirect™

Ethernet Bridge User's Guide

Page 11

Quatech, Inc. Confidential

Table 2. AirborneDirect™ Ethernet Bridge Indicator LEDs

LED

LED Color

Function

Off

Bridge is not receiving power.

Red

Bridge failed its Power On Self Test (POST) and is not configured
for wireless communication.

Amber

Bridge passed its POST but is not configured for wireless
communication.

Power

Green

Bridge passed its POST and is configured for wireless
communication.

Off

Bridge is not receiving power.

Blinking Red

Bridge is searching for an Access Point.

Link

Green

Wireless network and MAC have associated with an Access Point.

Off

No power, or no wireless TCP session is established and no
Ethernet physical connection is detected.

Red

No wireless TCP session is established; an Ethernet physical
connection is detected.

Blinking Red

An Ethernet physical connection was detected and there is Ethernet
traffic present on that connection, but no wireless TCP session is
established.

Amber

A wireless TCP connection is established but no physical Ethernet
connection is detected (i.e., no Ethernet cable is attached to the
Bridge).

Blinking Green

A wireless TCP session is established, a physical Ethernet
connection is detected, and the Bridge is transmitting or receiving
data across the wired Ethernet port.

Comm

Green

A wireless TCP session is established, a physical Ethernet
connection is detected, but there is no active data movement across
the wired Ethernet port.
