This chapter describes the

TT

AirborneDirect™ Ethernet Bridge.

TT

Topics in this chapter include:

ƒ

TT

Package Contents. (below)

ƒ

TT

Items Supplied by the User. (below)

ƒ

TT

Hardware Description. (page

XX

9

XX

)

ƒ

TT

Selecting a Location. (page

XX

13

XX

)

ƒ

TT

Configuring The Access Point. (page

XX

16

XX

)

ƒ

TT

Connecting the Bridge. (page

XX

17

XX

)

ƒ

TT

Verifying Your Connections. (page 21

XX

)

TT

STANDARD PACKAGE CONTENTS

TT

Before beginning the hardware installation, verify that the hardware package contains:

ƒ

One AirborneDirect™ Ethernet Bridge with an attached cable and an RJ-45 interface

connector.

ƒ

One AC power adapter and cord.

ƒ

One AirborneDirect™ mounting cradle (mounting hardware is user-supplied).


If you have the AirborneDirect™ Evaluation Kit, you should also have received:

ƒ

One Access Point (AP), IEEE 802.11b/g-compliant with DHCP enabled (optional).

ƒ

An AirborneDirect™ Ethernet Quick Start Guide.

ƒ

A CD containing this AirborneDirect™ Ethernet Bridge User’s Guide, the

AirborneDirect™ Ethernet Bridge Evaluation Kit Quick Start Guide, product briefs and
application notes, Adobe® Reader® for viewing the documents and an Airborne™
Control Center (ACC).


If any item is missing, damaged, or improperly functioning, contact Quatech.

CHAPTER 2

HARDWARE INSTALLATION
