Hardware Implementation
Quantum DLT 7000 Tape Drive
2-15
The ac power cord used with the tabletop tape unit must meet the following
criteria:
•
The power cord should be a minimum of 18/3 AWG, 60
°
C, Type SJT or SVT.
•
UL and CSA Certified cordage rated for use at 250 VAC with a current rating
that is at least 125% of the current rating of the product.
•
The ac plug must be terminated in a grounding-type male plug designed for
use in your country or region. It must also have marks showing certification
by an agency acceptable in your country or region.
•
The connector at the tabletop unit end of the cord must be an IEC type CEE-
22 female connector.
•
The cord must be no longer than 14.5 feet (4.5 meters).
Figure 2-7 shows different ac power cord plug-end configurations for 115 V and
220 / 240 V usage.
Figure 2–7 AC Power Cord Connector Types
115 V
220 / 240 V
